A TRAILER THAT LASTS

Tie Down white (3)-01.png

CARGO

TIEDOWNS

Tire - white 01-01.png

RADIAL

TIRES

Channel Icon white-01.png

3" CHANNEL

CROSSMEMBERS

Classic Carhauler



Pressure Treated Pine Floor

All our lumber is made and installed to withstand weather.

Premium Components
Arctic Wire Harness

We use brand name quality products for anything we don't produce in house

All our wire harnesses are sealed and the front hook up is rated for -65°F

3 Year Structural Warranty

All our frames are built tough and we back them up with a 3 year warranty.

Premium Powder Coat

We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.

Classic Carhauler



Classic Carhauler Specs

Electrical

LED Lights

Weather Resistant Harness

Cargo Loading

Rub Rail

Stake Pocket Tie Downs

Pair Of Slide-In Ramps

Color

Premium Powder Coat

GVWR

10,000lb GVWR

See options for exact sizes and payload

Brakes & Suspension

Ez Lube Idler Spring Axle

Electric Brake Spring Axle

Tires

225/75 R15 8Ply Tire

Black Wheel

Coupler

2-5/16" 12.5K Ram A-Frame Cast Coupler

Jack

2K Top-Wind Flip Jack

Frame

5" Channel Frame

Wrap Tongue

24" Center-To-Center Crossmembers

Treated Yellow Pine Floor



Completely Customizable

10K GVWR Sizes & Payload


Sizes - Weight - Payload

83" X 16' - 2150 lbs - 7850lbs

83" X 18' - 2210 lbs - 7790lbs

83" X 20' - 2265 lbs - 7735lbs

83" X 22' - 2635 lbs - 7365lbs

102" X 20' - 2770 lbs - 7230lbs

102" X 22' - 3000 lbs - 7000lbs




Brakes & Suspension


Standard -

5.2K Ez Lube Idler Spring Axle & Electric Brake Spring Axle

Optional -

5.2K Ez Lube Electric Brake Spring Axles




Cargo Loading


Standard -

Rub Rail

Stake Pockets Tie Downs

Pair Of Slide-In Ramps

Optional -

Deck Mount Winch Plate

17,500Lb Superwinch

12,000Lb Warn Winch

Extra Stake Pockets

Flush Mount Swivel D-Rings

Flush Mount D-Rings

Weld On D-Rings

Pair Of Support Stands

Pair Of 24" Wide Heavy Duty Stand-Up Ramps




Color


Standard -

Lamar Gray Powder Coat




Coupler


Standard -

2-5/16" 12.5K Ram A-Frame Cast Coupler

Optional -

2-5/16" 21K Demco Adj Cast Coupler




Electrical


Standard -

Led Lights

Weather Resistant Harness




Frame


Standard -

2' Dove

Wrap Tongue

5" Channel Frame

Smooth Teardrop Fenders

Drive Over Fenders

24" Center-To-Center Crossmembers

Treated Yellow Pine Floor

Optional -

11 Gauge Diamond Plate Floor

Removable Diamond Plate Fenders

16" Center-To-Center Crossmembers

Removable Smooth Teardrop Fenders

4' Dove

Diamond Plate Fenders

Straight Deck




Jack


Standard - 2K Top-Wind Flip Jack Optional -

Single 10K Drop-Leg Jack

7K Drop-Leg Jack




Other


Optional -

Front Tool Box

Receiver Hitch & Plug




Tires


Standard -

225/75 R15 8Ply Tire

Black Wheel

Optional -

Spare Tire Mount
Spare Tire

235/80 R16 10Ply Tire
